Autel Robotics EVO MAX 4T XE Gimbal
Autel Robotics EVO MAX 4T XE Bundle
Description
A wide variety of occupations and agencies can take advantage of the multi-sensor Gimbal Camera for EVO Max 4T XE from Autel Robotics. Packed into a single gimbal are a zoom camera, a wide-angle camera, a thermal camera, and a laser rangefinder. Get in close to your subject without flying in with the 48MP zoom camera, which offers 10x optical zoom and up to 160x hybrid digital zoom. It also captures video with 4000 x 3000 resolution footage at 30 fps. The wide-angle camera features the same video resolution while taking in more visual data with 48MP images that have a DFOV of 83.4°. When inspecting equipment or trying to locate someone, use the thermal camera's -4 to 1022°F temperature range. Finally, the laser rangefinder gives you a pinpoint location of objects with a 3.3' accuracy at distances of 16.4 to 3737'.
- For Autel Robotics EVO Max 4T XE
- 48MP Zoom & Wide Angle Cameras
- Thermal Camera with 640 x 512 Resolution
- Laser Rangefinder with 3.3' Accuracy
- 10x Optical & 160x Hybrid Digital Zoom
- 4000 x 3000 Resolution Video at 30 fps
- Diagonal Field of View of 83.4°
- -4 to 1022°F Temperature Range
- Measurement from 16.4 to 3737'
Product Specifications
Autel Robotics EVO MAX 4T XE Bundle Product Specifications
| Specification | Details |
|---|---|
| Compatibility | Autel Robotics EVO Max 4T XE |
| Zoom Camera – Sensor | 1/2" CMOS, 48 MP |
| Aperture | f/2.8 to f/4.8 |
| Optical Zoom (Continuous) | 2.7 to 10x |
| Maximum Hybrid Zoom | 160x |
| Video Resolution | 4000 × 3000 at 30 fps |
| Video Format | MP4 |
| Maximum Bit Rate | 70 Mb/s |
| Supported File Systems | exFAT / FAT32 |
| Photo Resolution (JPG) | 4000 × 3000; 8192 × 6144 |
| Photo Resolution (DNG) | 4000 × 3000 |
| Photo Format | JPG |
| Photo Taking Mode | Auto |
| DFOV | 40° to 10.3° |
| Effective Focal Length | 11.8 to 43.3 mm |
| 35mm Equivalent Focal Length | 64 to 234 mm |
| AF Type | PDAF + CDAF |
| Manual Focusing Distance | 6.6' (2 m) to Infinity |
| ISO Range (Auto/Manual) | 100 to 6400 |
| Shutter Speed (Photo) | 8 to 1/10,000 sec |
| Shutter Speed (Video) | 1/30 to 1/10,000 sec |
| Wide Angle Camera – Sensor | 1/2" CMOS, 48 MP (50 MP Effective) |
| Focal Length | 4.49 mm |
| Equivalent Focal Length | 24 mm |
| Aperture | f/2.8 |
| DFOV | 85° |
| AF Motor | FF |
| Focusing Distance | 4.9' (1.5 m) to Infinity |
| ISO Range (Auto/Manual) | 100 to 6400 |
| ISO Range (Supersensitive Mode, Auto) | 100 to 32,000 |
| Digital Zoom | 1 to 2.6x |
| Photo Size (JPG) | 4000 × 3000; 8192 × 6144 |
| Photo Size (DNG) | 4096 × 3072 |
| Photo Taking Mode | Auto / Manual |
| Video Resolution | 4000 × 3000 at 30 fps |
| Video Format | MP4 |
| Maximum Bit Rate | 70 Mb/s |
| Supported File Systems | exFAT / FAT32 |
| Thermal Sensor – Type | Uncooled VOx Microbolometer |
| Resolution | 640 × 512 |
| FOV | 61° |
| Focal Length | 9.1 mm |
| Aperture | f/1.0 |
| Focusing Distance | 19.7' (6 m) to Infinity |
| Pixel Pitch | 12 µm |
| Wavelength | 8 to 14 µm |
| Radiometric Measurement | Center / Spot / Rectangular |
| Radiometric Temp Range (High Gain) | -4 to 302°F (-20 to 150°C) |
| Radiometric Temp Range (Low Gain) | 32 to 1022°F (0 to 550°C) |
| Radiometric Temp Accuracy | ±3°C or ±3% (whichever greater) |
| Accurate Temp Measurement Distance | 3.3' to 82' (1 to 25 m) |
| Digital Zoom | 16x |
| Temperature Alert | High/Low thresholds with coordinate & temp report |
| Thermal Palettes | White Hot, Black Hot, Searing, Rainbow, Grey, Ironbow, Cold, Hot |
| Thermal Photo Format | JPG (with temperature data via SDK/PC tools) |
| Thermal Video Resolution | 640 × 512 at 30 fps |
| Thermal Video Format | MP4 |
| Laser Rangefinder | 905 nm wavelength |
| Measurement Range | 16.4 to 3737' (5 to 1200 m) |
| Measurement Accuracy | ±3.3' (1 m) + D × 0.15% |
| Gimbal – Mechanical Range (Pitch) | -135° to 45° |
| Mechanical Range (Roll) | -45° to 45° |
| Mechanical Range (Yaw) | -45° to 45° |
| Controllable Range (Pitch) | -90° to 30° |
| Max Control Speed (Pitch) | 100°/s |
| Angular Vibration Range | <0.005° |
| Power Source | Proprietary Interface |
| Package Weight | 2.585 lb |
| Box Dimensions (L×W×H) | 9.1 × 8 × 4.4 inches |
Product Manual
N/A
Product Warranty
Autel Robotics Warranty
| After-sales Type | Detail | The following conditions do not meet the return and exchange conditions |
|---|---|---|
|
Retreat |
Within 7 calendar days of product purchase: 1. The product packaging, accessories, gifts, manuals are complete, and there is no artificial damage, and it is not activated for use, which does not affect the second sale; 2. After the product is activated, there is a performance failure that is not artificially damaged. |
×The request for return is made more than 7 (15) calendar days from the date of receipt; ×Returned goods are incomplete, the outer packaging, accessories, gifts, and manuals are incomplete, or the appearance is artificially damaged; ×When returning the goods, it is impossible to provide legal proof of purchase or receipts, or to forge or alter the receipts; ×Product quality problems caused by collisions and burns that are not caused by quality problems of the product itself, as well as product quality problems caused by unauthorized modification, foreign objects (water, oil, sand, etc.), improper installation, use and operation not in accordance with the instructions in the manual; ×Torn or altered labels, machine serial numbers, waterproof marks, anti-counterfeit marks, etc.; ×Products damaged by force caused by unavoidable factors, such as fire, flood, lightning, traffic accidents, etc.; ×After contacting Autel Robotics customer service to confirm the return service, the corresponding item was not sent within 7 days. ×Other circumstances described in the policy. |
|
Change |
Within 15 calendar days of product purchase: 1. There is a performance failure that is not artificially damaged, and the machine is disassembled without permission; 2. During transportation, the product was damaged, and the transportation company provided proof of damage. |
|
|
Build |
1. In order to be covered by the warranty, the performance failure must be caused by a non-human error, and the purchased aircraft must be within the warranty period; 2. Any unauthorized dissassembly or modification of the aircraft with outside vendor parts will void the warranty; 3. Please provide valid proof of purchase, such as a bill or receipt. *Note (a) Free maintenance: the repaired parts inherit the warranty period of the whole machine or reset for 90 days, whichever is longer;
(b) Paid repairs: The warranty period for repaired parts will be recalculated;
(c) Selective maintenance, water ingress maintenance: the whole machine will be out of warranty;
(d) Discounted product replacement: Warranty period will be recalculated. |
×A collision or burn accident occurred due to man-made non-product quality problems; ×Damage caused by unauthorized modification, disassembly, or opening of the shell under the guidance of an unofficial manual; ×Damage or water ingress caused by incorrect installation, use and operation not in accordance with the instructions of the manual; ×In the absence of official instructions, the customer repairs the damage caused by the assembly by himself; ×Damage caused by circuit modification guided by unofficial manuals, or improper matching and use of battery packs and chargers; ×All damages caused by flying and shooting that are not operated in accordance with the product manual; ×Damage caused by manipulation in harsh environments, such as strong wind, rain, sand, etc.; ×Damage caused by manipulation in a complex electromagnetic environment or a strong interference source environment, such as mining areas, transmission towers, high-voltage lines, substations, etc.; ×Damage caused by manipulation in the case of mutual interference with other wireless devices, such as transmitter, image transmission signal, WiFi signal interference, etc.; ×Damage caused by take-off when the weight exceeds the safe take-off weight; ×Damage caused by forced flight when parts are aged or damaged; ×Damage caused by reliability or compatibility issues when used simultaneously with third-party components not certified by Autel Robotics; ×Damage caused by insufficient discharge when the battery is insufficient, or the use of a battery with quality problems; ×The machine serial number, factory label and other signs are torn or altered; ×After contacting Autel Robotics customer service to confirm the warranty service, the corresponding item was not sent within 7 calendar days. |
Aircraft Parts Warranty Period (Months)
| Product | Main Parts |
Warranty Period Months/In US |
Warranty Period Months/In EU |
Warranty Period Months/In APEC/SA/MENA |
|---|---|---|---|---|
| EVO Nano Series/EVO Lite Series/EVO II/EVO II PRO | Main Controller | 12 | 24 | 12 |
| Gimbal & Camera | 12 | 24 | 12 | |
| Vision Positioning System | 12 | 24 | 12 | |
|
Propulsion system (excluding propellers |
12 | 24 | 12 | |
| Remote Controller | 12 | 24 | 12 | |
| RC Charger | 12 | 24 | 12 | |
| Battery | 12 Months and Charge Cycle less than 200 Times, whichever go first. | 12 Months and Charge Cycle less than 200 Times, whichever go first. | 12 Months and Charge Cycle less than 200 Times, whichever go first. | |
| Battery Charger | 12 | 24 | 12 | |
| Propeller | - | - | - | |
| Dragonfish Lite/Dragonfish Standard/Dragonfish Pro | Main Controller | 12 | 24 | 12 |
| Gimbal & Camera(Z2/T3/T3H/M1/L20T/L50T) | 12 | 24 | 12 | |
|
Propulsion system (excluding propellers |
12 | 24 | 12 | |
| Remote Controller | 12 | 24 | 12 | |
| RC Charger | 12 | 24 | 12 | |
| Battery | 12 Months and Charge Cycle less than 200 Times, whichever go first. | 12 Months and Charge Cycle less than 200 Times, whichever go first. | 12 Months and Charge Cycle less than 200 Times, whichever go first. | |
| Battery Charger | 12 | 24 | 12 | |
| Base Station | 6 | 12 | 6 | |
| Base Station Turntable | 6 | 12 | 6 | |
| Base Station Tripod | 6 | 12 | 6 | |
| Base Station Charger | 6 | 12 | 6 | |
| EVO II Enterprise/EVO II RTK Series/EVO II Dual EVO Max Series EVO Lite Enterprise Series Autel Alpha |
Main Controller | 12 | 24 | 12 |
| Gimbal & Camera | 12 | 24 | 12 | |
| Vision Positioning System | 12 | 24 | 12 | |
|
Propulsion system (excluding propellers) |
12 | 24 | 12 | |
| Remote Controller | 12 | 24 | 12 | |
| RC Charger | 12 | 24 | 12 | |
| Battery | 12 Months and Charge Cycle less than 200 Times, whichever go first. | 12 Months and Charge Cycle less than 200 Times, whichever go first. | 12 Months and Charge Cycle less than 200 Times, whichever go first. | |
| Battery Charger | 12 | 24 | 12 | |
| Propeller | - | - | - | |
| Spotlight | 6 |
12 | 6 | |
| RTK Module | 6 | 12 | 6 | |
| Strobe | 6 | 12 | 6 | |
| Speaker | 6 | 12 | 6 | |
| Live Deck | Live Deck | 6 | 12 | 6 |
| EVO NEST | EVO NEST | 12 | 24 | 12 |
